4 Channel 0-10V Dimming Actuator

Model no.
MD041601
Color
White
Material
PP
Functional description
Parameter
Application scenarios
Download center
Functional description

(1) With 4-way 0-10V dimming interface;

(2) With 4-way 16A switch control;

(3) With manual control dimming function;

(4) With relative dimming function and absolute dimming function;

(5) With status report feedback function;

(6) With timing cycle function, it can realize stair light control and cycle flashing control;

(7) With on-site save and restore functions;

(8) Selection function of dimming output value and relay switching state after bus power failure and voltage recovery;

(9) With scene control function

(10) 4-way I/O dry contact input interface, which can input control commands such as switches, curtains, dimming, scenes, and fire protection;

(11) Scope of application: For all kinds of lamps driven by 0-10V dimming interface (downlight, spotlight, wall light, light strip, fluorescent lamp, etc.), for control equipment with 0-10V interface (0- 10V interface air conditioner, 0-10V fan coil unit, 0-10V fresh air system, etc.)

(12) I/O cable wiring distance: ≤10m

Parameter

Rated voltage:

200~240VAC, 50/60Hz
Bus voltage: 21-30 VDC, powered by KNX bus
Bus current: ≤12mA
Working power: ≤3.2W
Main output: 4-way 0-10V output
Output voltage: 0-10VDC (absorption type/output type), each circuit output Max.40mA
Relay switching current (per circuit): purely resistive load: Max 16A; incandescent lamp: Max 10A; fluorescent lamp with electronic ballast: Max 4 A
Working temperature: -5°…+45°C

Storage temperature:

-25°…+55°C
Transport temperature: -25°…+70°C
Relative humidity: Max 90%
Shell material: PA66
Dimensions (L x W x H): 144mm x 90mm x 64mm
Installation method: 35mm DIN rail installation
